KK-EX-20 Explosion-proof Electrical Actuator

KK-05 Electric Actuator

Stainless Steel Pneumatic Angle Seat Valve

Advantages:
Large flux, low resistance, no water-hammer
Y-type shape enlarged the flowing section, which could raise the flux by 30% and make flow more smooth.
Super Long Life
Which help the stem adjust and lubricate itself automatically.
The cylinder material is stainless steel.
Lubricating automatically, 360° rolling freely.

Pneumatic 3PC Threaded Ball Valve

Nominal diameter: DN15-DN100
Pressure range: ≤1000PSl(6.9Mpa)
Medium Temp: -20℃~+180°C
Environment Temp: -20℃~+60°C
Body material: Stainless steel
Sealing: PTFE
Body of actuator: Aluminium alloy
Control pressure: 3bar-8bar
Control feature: Double acting, Single acting
Standard: Rp(BSP); RC(BSPT); NPT
Applicable medium: water, gas, oil, acid, alkali, etc

Penumatic Wafer Type Kinfe Gate Valve

Wafer-Type Fire Fighting Handle Butterfly Valve

Wafer-Type Fire Fighting Handle Butterfly Valve
1.Specifications ①Nominal Working Pressure: 1.6MPa ②Test Pressure: Strength Test:2.4MPa Sealing Test: 1.76MPa ③Applicable Temperature: -10~80℃ ④Applicable Medium: Clear water, etc.
2.Materials of Valve Parts. ①Body: Ductile Iron ②Disc: Ductile Iron, Stainless Steel. ③Stem: Stainless Steel. ④Seat: PTFE, NBR ⑤Hand-wheel: High-Quality Carbon Structural Steel
