Submersible Sewage Pump(0.75-7.5Kw)
Head: Up to 42m
Liquid Temperature: ＜40ºC
Liquid Density: ≤1050kg/m3
PH Value: 4~10
keyword：
Valve
Submersible Sewage Pump(0.75-7.5Kw)
WQ/EC Small Submersible Sewage Pump Advantages:
1. Selected pump body and impeller
The CAD technology is used to repeatedly modify the design, so that the submersible water pump body and the impeller are optimally matched, and the fibers and debris are easy to pass without being entangled and blocked. The impeller is strictly balanced, so that the electric submersible pump has low vibration and stable operation.
2. Highly reliable submersible motor
The specially designed and manufactured submersible motor has a protection level of IP68 and the stator winding is F-class insulation. Due to the good cooling effect of submersible operation and the low actual temperature rise of the winding, the motor is more durable.
3. The motor has tight sealing and strict inspection
4. Reliable bearing configuration
The deep groove ball bearings of famous brand are selected, which have sufficient load margin to ensure the reliable operation of the products.
5. Jet mixing function
A jet mixing hole is opened on the submersible centrifugal pump body. When the pump is running, the pressure water in the pump forms a high-speed jet through the jet hole for powerful stirring, so that a large range of impurities are suspended, sucked in by the pump and discharged. No precipitation will be formed in a larger area, which is better than just mechanical stirring at the pump suction port.
6. Protection device
An overheating protection element is installed in the motor windings. When the winding temperature exceeds the specified temperature, the overheating protection element will turn on the "overheating" indicator light through the electric control cabinet and automatically shut down. Remind the operator to check to find out the cause of the motor overheating. After the temperature of the winding drops, the overheating protection element will automatically reset, and the motor can be turned on. However, it must not be turned on until the winding overheating is eliminated.
Suitable Applications:
· Municipal engineering
· Building construction
· lndustrial sewage
· Sewage treatment occasions to discharge sewage
· Waste water and rainwater containing solids and short fibers
Working Parameters:
· Flow: 5-150m3/h
· Head: Up to 42m
· Liquid Temperature: ＜40ºC
· Liquid Density: ≤1050kg/m3
· PH Value: 4~10
FAQ
Product After-Sales Service
We provide 1 year after-sales service for our products, and can extend the after-sales service period for a fee as needed. Please feel free to inquire in detail.
About Customized Product Production
We support customized production needs for various valve products, including OEM&ODM, provided that there is legal authorization. Please contact our sales manager on our website for more information.
About Our Factory
We have factories in Hunan, Zhejiang, Guangdong, and Shanghai in China, which can meet the production of various valves.
Product Production Cycle
We have a strong production team that schedules production based on the number of product orders and production processes. For standard products, we can generally complete production within 7-30 days and support expedited production.
About Logistics
We cooperate with powerful international logistics companies, whether it is air or sea freight, and we can apply for the best transportation price for you because we have rich experience in international logistics transportation.
